KEY FEATURE

• DSP/High-end micro controller based PWM technology using MOSFET: DSP/High-end micro controller used where the internal digital frequency control is at a speed of as high as 40 MIPS (millions instructions per Second).
• ACEC (Analog Compare Error Correction) technology based PWM for the generation of Pure Sine wave: Using ACEC technology the PWM is corrected.
• Boost Based PWM Controlled Intelligent Multistage Battery Management Charging Technology. The input power factor maintains 0.85 which reduce the electricity bills.
• Protections: Wiring Fault, Overload, Short Circuit, Battery low, Reverse Phase, Reverse Battery Protection.
• ASC (Assessing System Configuration) software technique is being incorporated. The software verifies all the critical system parameters before the system starts, & keep on assessing the system parameters while the system is running.
• Performance: Delivers unmatched noise free performance.
• UPS Mode: Very useful with computer type of application, Music studio or medical etc.
• Replicates Mains: Ensure same power quality as from mains with a crest factor of as high 3.7
• Display: LCD/LED Indication for status & Fault, Load & Battery Indication.
• PLPO: Peak load Peak Output ensures high load handling capacity.
• Generator Compatible.
•


• MODEL UPS

   JM SW 3750+/36V

   Capacity / Rating

   3.2KVA / 2560W

   Standard Input Voltage

   100V~280V

   Narrow Input Voltage

   180V~260V

   Output Voltage on Main Mode

   Same as Input

   Output Voltage on UPS mode

   220V+10%

   Output Frequency on UPS Mode

   50Hz+0.5Hz

   Switching form mains to UPS and UPS to mains

   Automatic

   Output wavefrom on mains mode

   Same as input

   Output wavefrom on backup mode

   Pure Sinewave

   Battery charging current

   Max Charge Current 20A+3A

   Battery Charger

   Boost Based PWM Control Multi-Stage IBM technology

   Efficinecy

   >80%

   Input Brown Out Voltage

   100V+10V

   UPS Overload

   108% of the Rated Capacity

   Technology

   DSP Based Smart Control Design

   Auto Reset Feature

   Yes

   Environmental Parameters

   Operating Temprature: 0~45*C  /  Acoustic Noise at 1 Mtr: <60dB
   Relative Humidity: MAX 95% Non Condensing  /  Thermal Management: Integrated cooling (Fan & Heat sink)

   Mains to Bypass

   Rotary/Rocker Bypass Switch

   Display

   LCD/LED Display Indicator
